Mô tả sản phẩm

Thiết bị tường lửa Firewall Fortinet FortiGate-1500D (FG-1500D-BDL-950-12)

Mã sản phẩm	FG-1500D-BDL-950-12
Interfaces and Modules
Hardware Accelerated 10 GE SFP+ / GE SFP Slots	8
Hardware Accelerated GE SFP Slots	16
Hardware Accelerated GE RJ45 Ports	16
GE RJ45 Management / HA Ports	2
USB Ports (Client / Server)	1 / 1
Console Port	1
Onboard Storage	2x 240 GB SSD
Included Transceivers	2x SFP+ (SR 10GE)
System Performance — Enterprise Traffic Mix
IPS Throughput	13 Gbps
NGFW Throughput	7 Gbps
Threat Protection Throughput	5 Gbps
System Performance and Capacity
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP)	80 / 80 / 55 Gbps
IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP)	80 / 80 / 55 Gbps
Firewall Latency (64 byte, UDP)	3 μs
Firewall Throughput (Packet per Second)	82.5 Mpps
Concurrent Sessions (TCP)	12 Million
New Sessions/Second (TCP)	300,000
Firewall Policies	100,000
IPsec VPN Throughput (512 byte)	50 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	20,000
Client-to-Gateway IPsec VPN Tunnels	100,000
SSL-VPN Throughput	4 Gbps
Concurrent SSL-VPN Users (Recommended Maximum)	10,000
SSL Inspection Throughput (IPS, avg. HTTPS)	5.7 Gbps
SSL Inspection CPS (IPS, avg. HTTPS)	3,100
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	800,000
Application Control Throughput (HTTP 64K)	16 Gbps
CAPWAP Throughput (1444 byte, UDP)	20 Gbps
Virtual Domains (Default / Maximum)	10 / 250
Maximum Number of FortiSwitches Supported	128
Maximum Number of FortiAPs (Total / Tunnel)	4,096 / 2,048
Maximum Number of FortiTokens	20,000
Maximum Number of Registered Endpoints	20,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Dimensions and Power
Height x Width x Length (inches)	3.5 x 17.24 x 21.81
Height x Width x Length (mm)	89 x 438 x 554
Weight	32.50 lbs (14.70 kg)
Form Factor	Rack Mount, 2 RU
AC Power Supply	100–240V AC, 50–60 Hz
Power Consumption (Average / Maximum)	336 / 403.2 W
Current (Maximum)	110V / 5.5A, 220V / 3A
Heat Dissipation	1,375 BTU/h
Redundant Power Supplies	Yes (Hot Swappable)
Operating Environment and Certifications
Operating Temperature	32–104°F (0–40°C)
Storage Temperature	-31–158°F (-35–70°C)
Humidity	10–90% non-condensing
Noise Level	59 dBA
Operating Altitude	Up to 7,400 ft (2,250 m)
Compliance	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
Certifications	ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6

Tùy chọn Module quang SFP cho Firewall FortiGate 1500D

1 GE SFP LX Transceiver Module	FN-TRAN-LX	1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots.
1 GE SFP RJ45 Transceiver Module	FN-TRAN-GC	1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+slots.
1 GE SFP SX Transceiver Module	FN-TRAN-SX	1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots.
10 GE SFP+ RJ45 Transceiver Module	FN-TRAN-SFP+GC	10 GE SFP+ RJ45 transceiver module for systems with SFP+ slots
10 GE SFP+ Transceiver Module, Short Range	FN-TRAN-SFP+SR	10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots.
10 GE SFP+ Transceiver Module, Long Range	FN-TRAN-SFP+LR	10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots.
10 GE SFP+ Transceiver Module, Extended Range	FN-TRAN-SFP+ER	10 GE SFP+ transceiver module, extended range for all systems with SFP+ and SFP/SFP+ slots
10 GE SFP+ Active Direct Attach Cable, 10m / 32.8 ft	SP-CABLE-ADASFP+	10 GE SFP+ active direct attach cable, 10m / 32.8 ft for all systems with SFP+ and SFP/SFP+ slots.

Tùy chọn Rack Mount cho Firewall Fortigate 1500D

Rack Mount Sliding Rails

SP-FG3040B-RAIL

Rack mount sliding rails for FG-1000C/-DC, FG-1100/1101E, FG-1200D, FG-1500D/-DC, FG-2000E, FG-2500E, FG-3040B/-DC, FG-3140B/-DC, FG-3240C/-DC, FG-3000D/-DC, FG-3100D/-DC, FG-3200D/-DC, FG-3400/3401E, FG-3600/3601E, FG-3700D/-DC, FG-3700DX, FG-3810D/-DC and FG-3950B/-DC.

Tùy chọn Power nguồn cho Firewall FortiGate 1500D

AC Power Supply

SP-FG1200D-PS

AC power supply for FG-1200D, FG-1500D and FG-1500DT.

Xem thêm

Thông số kỹ thuật

Hardware plus 1 Year 24x7 FortiCare and FortiGuard UTP Bundle (FG-1500D-BDL-950-12)
- Hardware: 8x 10 GE SFP+ slots, 16x GE SFP slots, 18x GE RJ45 ports (including 16x ports, 2x management/HA ports), SPU NP6 and CP8 hardware accelerated, 480 GB SSD onboard storage, dual AC power supplies.
- 1 Year Hardware plus 24x7 FortiCare and FortiGuard Unified Threat Protection (UTP) (IPS, Advanced Malware Protection, Application Control, Web & Video Filtering, Antispam Service)

Data sheet Fortinet FortiGate 1500D

Xem thêm thông số kỹ thuật
