Mô tả sản phẩm

Thiết bị tường lửa Firewall Fortinet FortiGate-800D (FG-800D-BDL-950-12)

Mã sản phẩm	FG-800D-BDL-950-12
Interfaces and Modules
Hardware Accelerated 10 GE SFP+ Slots	2
Hardware Accelerated GE SFP Slots	8
Hardware Accelerated GE RJ45 Ports	20
Accelerated GE RJ45 Bypass Interfaces	4
GE RJ45 Management / HA Ports	2
USB Ports (Client / Server)	1 / 2
Console Port	1
Onboard Storage	1x 240 GB SSD
Included Transceivers	2x SFP (SX 1 GE)
System Performance — Enterprise Traffic Mix
IPS Throughput 2	4.2 Gbps
NGFW Throughput 2, 4	4 Gbps
Threat Protection Throughput 2, 5	3 Gbps
System Performance and Capacity
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP)	36 / 36 / 22 Gbps
IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP)	36 / 36 / 22 Gbps
Firewall Latency (64 byte, UDP)	3 μs
Firewall Throughput (Packet per Second)	33 Mpps
Concurrent Sessions (TCP)	5 Million
New Sessions/Second (TCP)	280,000
Firewall Policies	10,000
IPsec VPN Throughput (512 byte)	20 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	50,000
SSL-VPN Throughput	2.2 Gbps
Concurrent SSL-VPN Users (Recommended Maximum)	5,000
SSL Inspection Throughput (IPS, avg. HTTPS)3	3.9 Gbps
SSL Inspection CPS (IPS, avg. HTTPS) 3	2,400
SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3	380,000
Application Control Throughput (HTTP 64K) 2	9 Gbps
CAPWAP Throughput (1444 byte, UDP)	5.5 Gbps
Virtual Domains (Default / Maximum)	10/10
Maximum Number of FortiSwitches Supported	64
Maximum Number of FortiAPs (Total / Tunnel)	1024 / 512
Maximum Number of FortiTokens	5,000
Maximum Number of Registered Endpoints	2,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Dimensions and Power
Height x Width x Length (inches)	1.75 x 17.0 x 16.4
Height x Width x Length (mm)	44.45 x 432 x 416
Weight	19.0 lbs (8.6 kg)
Form Factor	1 RU
AC Power Supply	100–240V AC, 60–50 Hz
Power Consumption (Average / Maximum)	128 W / 187 W
Current (Maximum)	110V/7A, 220V/3.5A
Heat Dissipation	636 BTU/h
Redundant Power Supplies	(Hot Swappable) optional
Operating Environment and Certifications
Operating Temperature	32–104°F (0–40°C)
Storage Temperature	-31–158°F (-35–70°C)
Humidity	10–90% non-condensing
Noise Level	49.9 dBA
Operating Altitude	Up to 7,400 ft (2,250 m)
Compliance	FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB
Certifications	ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN;USGv6/IPv6

Tùy chọn Module quang SFP cho Firewall FortiGate 800D

1 GE SFP LX transceiver module	FN-TRAN-LX	1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots.
1 GE SFP RJ45 transceiver module	FN-TRAN-GC	1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+slots.
1 GE SFP SX transceiver module	FN-TRAN-SX	1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots.
10 GE SFP+ Transceiver Module, Short Range	FN-TRAN-SFP+SR	10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots
10 GE SFP+ Transceiver Module, Long Range	FN-TRAN-SFP+LR	10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots
10 GE SFP+ Active Direct Attach Cable, 10m / 32.8 ft	SP-CABLE-ADASFP+	10 GE SFP+ active direct attach cable, 10m / 32.8 ft for all systems with SFP+ and SFP/SFP+ slots

Tùy chọn Power nguồn cho Firewall FortiGate 800D

AC Power Supply

SP-FG600C-PS

AC power supply for FG-600C, FG-800C, FG-800D and FG-1000C.

Xem thêm

Thông số kỹ thuật

Hardware plus 1 Year 24x7 FortiCare and FortiGuard UTP Bundle (FG-800D-BDL-950-12)
- Hardware : 22x GE RJ45 ports, 4x GE RJ45 with Bypass Protection, 8x GE SFP slots, 2x 10 GE SFP+ slots, SPU NP6 and CP8 hardware accelerated, 240 GB Internal onboard SSD storage.
- 1 Year Hardware plus 24x7 FortiCare and FortiGuard Unified Threat Protection (UTP) (IPS, Advanced Malware Protection, Application Control, Web & Video Filtering, Antispam Service)

Data sheet Fortinet Fortigate 800D

Xem thêm thông số kỹ thuật
