Bộ định tuyến bảo mật Wi-Fi 5 băng tần kép Planet VR-300PW5 với hỗ trợ VPN và 4 cổng PoE+
Bộ định tuyến VPN WiFi băng tần kép Planet VR-300PW5 hỗ trợ chuẩn 802.11ac với tốc độ lên đến 867Mbps trên băng tần 5GHz, tích hợp 4 cổng LAN Gigabit hỗ trợ PoE+ (802.3at) với tổng công suất 120W, cho phép cấp nguồn trực tiếp cho các thiết bị như camera IP hoặc access point. Thiết bị trang bị 4 ăng-ten độ nhạy cao, bộ khuếch đại công suất và công suất phát điều chỉnh linh hoạt, đảm bảo vùng phủ sóng rộng và ổn định. Hệ thống bảo mật nâng cao gồm tường lửa SPI, lọc nội dung, hỗ trợ VPN, cùng bộ điều khiển AP, RADIUS và giao diện quản lý trực quan. Đây là giải pháp mạng toàn diện cho doanh nghiệp vừa và nhỏ.
Các tính năng chính Bộ định tuyến bảo mật VPN Wifi băng tần kép Planet VR-300PW5 :
.Thông số kỹ thuật
| Hardware Specifications | |
| Ethernet | 5 10/100/1000BASE-T RJ45 Ethernet ports including |
| 3 LAN ports (Ports 1 to 3) | |
| 1 LAN/WAN port (Port 4) | |
| 1 WAN port (Port 5) | |
| USB Port | 1 USB 3.0 port for system configuration backup and restore |
| Reset Button | Reset to factory default |
| Thermal Fan | 1 |
| LED Indicators | PWR (Green) |
| Internet (Green) | |
| LAN/WAN (Green) | |
| 2.4G (Green) | |
| 5G (Green) | |
| PoE-in-Use LED (Amber) | |
| Installation | Desktop installation or rack mounting |
| Power Requirements | 100~240V AC, 50/60Hz, auto-sensing |
| Power Consumption / Dissipation | Max. 140W/477.7BTU |
| Weight | 1.7kg |
| Dimensions (W x D x H) | 330.2 x 153 x 44 mm, 1U height |
| Enclosure | Metal |
| Power over Ethernet | |
| PoE Standard | IEEE 802.3af / 802.3at PoE+ PSE |
| PoE Power Supply Type | End-span |
| PoE Power Output | Per port 52V DC, 36 watts (max.) |
| Power Pin Assignment | 1/2 (+), 3/6 (-) |
| PoE Power Budget | 120 watts (max.) @ 25 degrees C |
| 100 watts (max.) @ 50 degrees C | |
| Max. Number of Class 4 PDs | 4 |
| PoE Management | PD Alive Check |
| Scheduled Power Recycling | |
| PoE Schedule | |
| PoE Usage Monitoring | |
| Wireless | |
| Standard | IEEE 802.11 b/g/n 2.4 GHz |
| IEEE 802.11 a/n/ac 5 GHz | |
| Band Mode | 2.4G / 5G concurrent mode |
| Frequency Range | 2.4GHz |
| America FCC: 2.412~2.462GHz | |
| Europe ETSI: 2.412~2.484GHz | |
| 5GHz | |
| America FCC: 5.180~5.240GHz, 5.725~5.850GHz | |
| Europe ETSI: 5.180~5.240GHz | |
| Operating Channels | 2.4GHz |
| America FCC: 1~11 | |
| Europe ETSI: 1~13 | |
| 5GHz | |
| America FCC: | |
| Non-DFS: 36, 40, 44, 48, 149,153,157,161,165 | |
| DFS: 52, 56, 60, 64, 100, 104, 108, 112, 116, 132, 136, 140 | |
| Europe ETSI: | |
| Non-DFS: 36, 40, 44, 48 | |
| DFS: 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140 | |
| 5GHz channel list will vary in different countries according to their regulations. | |
| Channel Width | 802.11ac: 20/40/80MHz |
| 802.11n: 20/40MHz | |
| Data Transmission Rates | Transmit: 300 Mbps* for 2.4 GHz and 867 Mbps* for 5 GHz |
| Receive: 300 Mbps* for 2.4 GHz and 867 Mbps* for 5 GHz | |
| *The estimated transmission distance is based on the theory. The actual distance will vary in different environments. | |
| Transmission Power | <=20dBm (2.4G frequency band: 2.400 – 2.4835 GHz) |
| <=23dBm (5G frequency band: 5.150 – 5.350 GHz) | |
| Encryption Security | WEP (64/128-bit) encryption security |
| WPA / WPA2 (TKIP/AES) | |
| WPA-PSK / WPA2-PSK (TKIP/AES) | |
| 802.1x Authenticator | |
| Wireless Advanced | Wi-Fi Multimedia (WMM) |
| Auto channel selection | |
| Wireless output power management | |
| MAC address filtering | |
| Security Service | |
| Firewall Security | Cybersecurity |
| Stateful Packet Inspection (SPI) | |
| Blocks DoS/DDoS attack | |
| ALG (Application Layer Gateway) | SIP, RTSP, FTP, H.323, TFTP |
| NAT | Port forwarding |
| DMZ Host | |
| UPnP | |
| Content Filtering | MAC filtering |
| IP filtering | |
| Web filtering | |
| Bandwidth Management | Outbound load balancing |
| Failover for dual-WAN | |
| QoS (Quality of Service) | |
| Networking | |
| Operation Mode | Routing mode |
| Routing Protocol | Static Route, Dynamic Route (RIP), OSPF |
| VLAN | 802.1q Tag-based, Port-based, Multi-VLAN |
| Multicast | IGMP Proxy |
| NAT Throughput | Max. 900Mbps |
| Outbound Load Balancing | Supported algorithms: Weight |
| Protocol | IPv4, IPv6, TCP/IP, UDP, ARP, HTTP, HTTPS, NTP, DNS, PLANET DDNS, PLANET Easy DDNS, DHCP, PPPoE, SNMPv1/v2c/v3, |
| Key Features | HA (High Availability) |
| Captive Portal | |
| RADIUS Server/Client | |
| AP Control | |
| VPN | |
| VPN Function | IPSec/Remote Server (Net-to-Net, Host-to-Net) |
| GRE | |
| PPTP Server | |
| L2TP Server | |
| SSL Server/Client (Open VPN) | |
| VPN Tunnels | Max. 60 |
| VPN Throughput | Max. 60Mbps |
| Encryption Methods | DES, 3DES, AES or AES-128/192/256 encrypting |
| Authentication Methods | MD5/SHA-1/SHA-256/SHA-384/SHA-512 authentication algorithm |
| Management | |
| Basic Management Interfaces | Web browser |
| SNMP v1, v2c | |
| PLANET Smart Discovery utility/UNI-NMS supported | |
| Secure Management Interfaces | SSHv2, TLSv1.2, SNMP v3 |
| System Log | System Event Log |
| Others | Setup wizard |
| Dashboard | |
| System status/service | |
| Statistics | |
| Connection status | |
| Auto reboot | |
| Diagnostics | |
| Standards Conformance | |
| Regulatory Compliance | CE, FCC |
| Environment Specifications | |
| Operating | Temperature: 0 ~ 50 degrees C |
| Relative Humidity: 5 ~ 95% (non-condensing) | |
| Storage |
Temperature: -10 ~ 60 degrees C
|
