Product	BPL-310X-5GD-T
WAN Interface	1x Embedded 5G Modem with Redundant SIM Slots 2x 10/100/1000M Ethernet 2x USB 2.0 Interface
LAN Interface	9x 10/100/1000M Ethernet
Router Throughput	2.5 Gbps
PepVPN Throughput	No Encryption: 600 Mbps 256-bit AES: 500 Mbps
5G Cellular Data Rate (Downlink/Uplink)	5G: 4 Gbps / 700 Mbps LTE CAT-20: 2 Gbps / 150 Mbps
Recommended Users	50-500
Antenna Connector	4x SMA Cellular Antenna Connectors 1x SMA GPS Antenna Connector
Power Input	Power Din DC: 12V – 30V
Power Consumption	30W (max.)
Dimensions	43 x 292 x 177 mm
Weight	3.3 kg
Operating Temperature	-40° – 65 °C
Humidity	10%–95% (non-condensing)
Certifications	FCC, CE, RoHS
Package Content	Balance 310X 5G, 1x PSU 24V 2.5A (ACW-647), 4x LTE/5G Antennas (ACW-235) 1x GPS Antenna (ACW-232), 1 Pair of Mounting Brackets (ACW-513) Rubber Foot Pad Set, Grounding Cable
Expansion Module for B310X 5G
EXM-310X-5GD	Expansion Module for B310X with 1x 5G modem
Featured Add-on
SFN-LC-50	Up to 50 SpeedFusion Peers License Key for Balance 310X
SFN-LC-30	Up to 30 SpeedFusion Peers License Key for Balance 310X
ECP-BPL-310X-5G-xY	EssentialCare+ (x-Year) for Balance 310X 5G x = 1, 2, 4 years
SVL-BPL-310X-5G-zY	EssentialCare for Balance 310X 5G z = 1,2 years
LIC-VWAN	Activate 1/2/3x Virtual WAN

Data sheet Peplink Balance 310X 5G

PEPLINK BALANCE 310X 5G FEATURES

WAN
- Support for PPPoE, Static IP, DHCP
- WAN Link Health Check
  - PING
  - IPv6 Support
  - DNS Lookup
  - HTTP
- Bandwidth Allowance Monitor
- USB 4G/3G Modem Support
- Intelligent Failover
- Support for Dynamic DNS services
  - changeip.com
  - dyndns.org
  - no-ip.org
  - tzo.com
  - DNS-O-Matic
LAN
- DHCP Server for LAN Clients
- Extended DHCP Option
- DHCP Reservation
- DNS Proxy for LAN Clients
- VLAN on LAN Support
Load Balancing
- Intelligent Failover
- Session Persistence
- Per-Service Load Distribution
- Multiple Algorithms
  - Weighted
  - Enforced
  - Persistence
  - Priority
  - Overflow
  - Least Used
  - Lowest Latency
  - Fastest Response Time
Security
- DoS Prevention
- Stateful Firewall
- Web Blocking
- Web Filtering Blacklist
Complete VPN Solution
- SpeedFusion VPN
- Site-to-Site VPN
  - Bandwidth Bonding
  - Hot Failover
  - 256-bit AES Encryption
  - Pre-shared Key Authentication
  - Dynamic Routing
- PPTP/L2TP/OpenVPN Server
  - Local User Active Directory Authentication
- IPsec VPN (Network-to-Network)
  - X.509 Certificate Support
- GRE Tunnel (Network-to-Network)
Advanced QoS
- User Groups
  - Bandwidth Reservation
  - Individual Bandwidth Limit
- Application Prioritization
  - By User Groups
  - SIP, HTTPS, VPN QoS
  - Custom Application QoS
Networking
- NAT and IP Forwarding
- Static Routes
- Port Forwarding
- Many to One, One to One NAT
- NAT Pool
- SIP ALG, H.323 ALG
- UPnP, NAT-PMP
- WINS Server
- VRRP HA Support
- BGP, OSPFv2 and RIPv2 Support
AP Controller
- Support for Pepwave AP Series
- Auto AP Discovery
- Auto AP Firmware Management
- AP Profile Configuration
- Wi-Fi Usage Statistics
Captive Portal
- Support for Wired and Wireless LAN Clients
- Support RADIUS Authentication
- Support LDAP Authentication
- Time and Usage Quotas on Open Access Mode
- Built-in Customizable Splash Page
DNS
- Built-in Authoritative DNS
- Support for A, CNAME, NS, MX, PTR, SOA, SRV, TXT records
Device Management
- Web Administrative Interface
- Command Line Interface
- InControl Cloud Management
- Email Notification
- Active Client and Session Lists
- Bandwidth Usage Statistics
- Syslog Service
- SNMP v1, v2c and v3
