Mô tả sản phẩm

Thiết bị chuyển mạch Switch Juniper EX4600-40F-AFI

Model	EX4600-40F-AFI
Hardware	• Switching capacity: 720 Gbps (unidirectional)/1.44 Tbps (bidirectional) • Layer 2/Layer 3 throughput (maximum with 64 byte packets): 1,071 Mpps • Weight: 9.84 kg with PSUs and fans installed • Dimensions (HxWxD): 4.37 x 44.09 x 52.02 cm • Switching mode: Cut-through and store-and-forward • Back-to-front airflow • Management and rear console port connections • Predicted mean time between failures (MTBF): 150,000 hours • Predicted FIT rate: 4,987
Interface Options	• 1GbE SFP: 24(40) (with 10GbE expansion modules) • 10GbE SFP+: 24(40/72) (with 10GbE expansion modules/with fixed 40GbE ports using breakout cables) • 40GbE QSFP+: 4(12) (with expansion modules) ₀ Each fixed QSFP+ port can be configured as a 4x10GbE interface ₀ Each QSFP+ port can be configured as a 40 Gbps port ₀ USB port ₀ Console port ₀ 2 management ports: 1 RJ-45 and 1 SFP ₀ Supported transceiver and direct attach cable ₀ SFP+ 10GbE optical modules ₀ SFP+ DAC cables: 1/3/5 m direct-attached copper and 1/3/5/7/10 m active direct-attached copper ₀ SFP GbE optical and copper module ₀ QSFP+ to SFP+ 10GbE direct attach break-out copper (1/3 m direct-attached copper cable)
Rack Installation Kit	• Versatile four post mounting options for 19-in server rack or datacom rack
Airflow	• Front-to-back and back-to-front cooling • Redundant variable-speed fans to reduce power draw
Power Supply and Fan Modules	• Dual redundant (1+1) and hot-pluggable power supplies • 110-240 V single phase AC power • Redundant (N+1) and hot-pluggable fan modules for back-to-front airflow
Performance Scale (Unidimensional)	• MAC addresses per system: 288,000 • VLAN IDs: 4,091 • Number of ports per LAG: 32 • FCoE scale: Number of FCoE VLANs/FC virtual fabrics: 4,095 • Firewall filters: 4,000 • IPv4 unicast routes: 128,000 prefixes; 208,000 host routes • IPv4 multicast routes: 104,000 • IPv6 multicast routes: 52,000 • IPv6 unicast routes: 64,000 prefixes • Address Resolution Protocol (ARP) entries: 48,000 • Jumbo frame: 9,216 bytes
Environmental Ranges	• Operating temperature: 0° to 40° C • Storage temperature: -40° to 70° C • Operating altitude: up to 2,000 • Relative humidity operating: 5% to 90% (noncondensing) • Relative humidity nonoperating: 0% to 95% (noncondensing)

Tùy chọn Module cho Switch Juniper EX4600-40F-AFI

QFX-EM-4Q	4-port QSFP+ expansion module for EX4600
EX4600-EM-8F	8-port SPF+/SFP expansion module for EX4600

Xem thêm

Thông số kỹ thuật

EX4600-40F-AFI : 24 SFP+/SFP ports, 4 QSFP+ ports, 2 expansion slots, redundant fans, 2 AC power supplies, 2 power cords, 4-post rack mount kit, and back to front airflow

Data sheet Juniper EX4600 Ethernet Switch

Xem thêm thông số kỹ thuật
