Thiết bị Router cân bằng tải Draytek Vigor2927
Product | Vigor2927 |
---|---|
PHẦN CỨNG | |
Port | ● 2 x GbE WAN ● 5 x GbE LAN ● 2 x USB 2.0 |
Nguồn
|
DC 12V/2A |
Nút điều khiển | 1 x Factory Reset Button |
Kích thước (L*W*H)
|
241mm x 165mm x 44mm |
PHẦN MỀM | |
WAN | Ethernet WAN ● DHCP Client ● Static IP ● PPPoE ● PPTP / L2TP (WAN-2 only) ● 802.1q Multi-VLAN Tagging IPv6 Connection Type ● Dual Stack: PPP, DHCPv6 Client, Static IPv6 ● Tunnel Mode: TSPC, AICCU, 6rd, 6in4 Static Tunnel USB WAN ● PPP(3G) / CDC driver(3G) / support IPv6 protocol :TSPC/AICCU Dual WAN ● Load-Balance / Route Policy ● Outbound policy-based load-balance ● WAN Connection Failover ● Multiple-VLAN |
Network | Hotspot Web Portal Packet Forwarding Acceleration DHCP client/relay/server DHCP Option: 1,3,6,51,53,54,58,59,60,61,66,125 IGMP v2/v3 LAN DNS /DNS Forwarding Dynamic DNS NTP Client RADIUS /TACACS+ Client Internal RADIUS Server Active Directory /LDAP compatible (client) DNS Cache/Proxy and LAN DNS UPnP 50 sessions Wake on LAN Bonjour service Routing Protocol: ● Static Routing ● RIP v1/v2 ● BGP Triple-Play Application ● IGMP snooping/proxy 8 x Multiple Subnet LAN |
Management | Web-based User Interface (HTTP/HTTPS) CLI (Command Line Interface, Telnet/SSH) Administration Access Control Configuration Backup/Restore Built-in Diagnostic Function Firmware Upgrade via TFTP/HTTP/TR-069 Logging via Syslog SNMP V2/V3 Support SMS/E-mail Alert Management Session Time Out Two-level Management (Admin/User Mode) External device detection (master mode) TR-069/TR-104 Support Multiple-Firmware Upgrade Utility (MFUU) Dashboard |
Chất lượng dịch vụ | QoS: ● Guarantee Bandwidth for VoIP ● Class-based Bandwidth Guarantee by User-defined Traffic Categories ● DiffServ Code Point Classifying ● 4-level Priority for Each Direction (Inbound/Outbound) ● Bandwidth Borrowed Bandwidth/Session limitation ● Smart Bandwidth Limit config by ip range ● Layer-3 (TOS/DSCP) QoS Layer-2 (802.1p) QoS WAN budget |
VPN | Up to 50 VPN Tunnels (including 25 SSL VPN tunnels) VPN Wizard VPN Trunk with Backup / Load Balance Protocol : PPTP, IPsec, L2TP, L2TP over IPsec, GRE over IPSec Encryption : MPPE and hardware-based AES/DES/3DES Authentication : SHA IKE Authentication : Pre-shared Key and Digital Signature (X.509) LAN-to-LAN, Teleworker-to-LAN (remote user dial-in) DHCP over IPsec IPsec NAT-traversal (NAT-T) Dead Peer Detection (DPD) VPN Pass-through mOTP |
Tính năng nâng cao | Firewall ● DMZ Host:Port-redirection, Open Port, Port Triggering ● User-based / Rule-based Firewall ● Object-based Firewall:SPI (Stateful Packet Inspection) (Flow Track) ● DoS Prevention ● Time Schedule Control ● DNS Filter Enhancement ● User Management ● Firewall Wizard Mode and Advanced Mode CSM (Content Security Management) ● APP Enforcement ♦ Support APPE Signature Upgrade by license ● URL Content Filter: ♦ Access Control : URL Keyword Blocking (White/Black List) ♦ Web Feature : Java Applet, Cookies, Active X, Compressed, Executable, Multimedia File Blocking ● Web Content Filter (support Cyren and BPjM) ● DNS Filter Central Device Management ● AP Management ● VPN Management ● Switch Management ● External Devices |
USB | ● File System ● Support FAT32 File System ● Support FTP Function for File Sharing ● 3.5G (HSDPA) and 4G (LTE) as WAN3/WAN4 by using USB dongle (can support Dual USB WAN) ● USB Device Status (disk/modem/printer/sensor) ● Support USB Temperature Sensor ● Support file sharing (DrayTek’s own SMB protocol stack) |
THÔNG SỐ KHÁC | |
Môi trường
|
Temperature Operating : 0°C ~ 45°C Temperature Storage : -25°C ~ 70°C Humidity :10% ~ 90% ( non-condensing ) |
