Thiết bị chuyển mạch Ubiquiti Switch Mission Critical (USW-Mission-Critical)
| Model | USW-Mission-Critical | |
|---|---|---|
| Mechanical | ||
| Dimensions | 442 x 480 x 44 mm (17.4 x 18.9 x 1.7") | |
| Weight | Without Mount: 9.01 kg (19.86 lb) With Mount: 9.2 kg (20.28 lb) |
|
| Enclosure material | SGCC Steel | |
| Mount Material | SGCC Steel | |
| Hardware | ||
| Total non-blocking throughput | 9 Gbps | |
| Switching capacity | 18 Gbps | |
| Forwarding rate | 26.78 Mpps | |
| Max. Power Consumption | 240W | |
| Max. Power Consumption (Excluding PoE Output) | 50W (10 + 40W Internal Chargers) | |
| PoE Budget | 120W | |
| Power Method | (1) Universal AC input, 100-240VAC, 4.4A Max, 50/60 Hz (1) DC Input for External 48VDC Battery (1) Internal Lithium-Ion Battery, 368Wh |
|
| Power Supply | Universal AC Input: AC/DC, Internal, 240W External Battery Port: DC, External, 240W |
|
| Power Output | (2) Power Control Outlets, 100-120VAC, 0.8A Max., 60Hz | |
| Power Output Budget | 80W | |
| Networking Interface | (9) 10/100/1000 Mbps Ethernet RJ45 Ports | |
| PoE Interfaces | (4) PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-) (4) 60W PoE++ IEEE 802.3bt (Pair A 1, 2+; 3, 6-)(Pair B 4, 5+; 7, 8-) |
|
| Max PoE+ Wattage per Port by PSE (AT) | 32W | |
| Max PoE+ Wattage per Port by PSE (BT) | 64W | |
| Voltage Range 802.3af Mode | 44-57V | |
| Voltage Range 802.3at Mode | 50-57V | |
| LCM Display | (1) 1.3" Touchscreen Bootup Animation: Bootup in Progress Firmware Upgrade Icon: Firmware Upgrading Steady White: Factory Defaults, Awaiting Adoption Steady Blue: Device is Adopted |
|
| Management Interface | Ethernet In-Band | |
| Modes | SMB Layer 2 PoE Gigabit Ethernet Switch | |
| ESD/EMP protection | Air/Contact: ± 24 kV | |
| Operating Temperature | -5 to 40° C (23 to 104° F) | |
| Operating Humidity | 5 to 95% non-condensing | |
| Certifications | FCC, IC | |
Data sheet Ubiquiti Switch Mission Critical (USW-Mission-Critical)
