TP-Link SX6632YF : Omada Stackable L3 Managed Aggregation Switch 26 cổng 10G với 6 khe 25G
TP-Link SX6632YF là L3 Managed Switch với cổng quang, với 6 khe cắm SFP28 25 Gbps, 26 khe cắm SFP+ 10 Gbps và khả năng xếp chồng vật lý. Tích hợp với các tính năng bảo mật mạnh mẽ và quản lý toàn diện, switch này đảm bảo hiệu suất đáng tin cậy cho các mạng SMB, doanh nghiệp và ISP.
Những đặc điểm nội trội của TP-Link SX6632YF
Thông số kỹ thuật
| Sản phẩm | SX6632YF |
| TÍNH NĂNG PHẦN CỨNG | |
| Giao diện | • 6× 10/25G SFP28 Slots • 26× 1/10G SFP+ Slots • 2× USB 3.0 Ports • 1× RJ45 Console Port • 1× USB Type C Console Port • 1× RJ45 Management Port |
| Số lượng quạt | 4x khe có thể thay thế và các quạt có thể tháo lắp nóng (dự phòng N+1) |
| Bộ cấp nguồn | 2x khe cắm bộ nguồn có thể thay thế và tháo lắp lắp (100–240 VAC, 50/60 Hz) |
| Điện năng tiêu thụ | 86.7 W (110 V/60 Hz) |
| Kích thước ( R x D x C ) | 17.3 × 15.0 × 1.7 in (440 × 380 × 44 mm) |
| Lắp | Rack Mountable |
| Max Heat Dissipation | 295.85 BTU/hr (110 V/60 Hz) |
| HIỆU SUẤT | |
| Switching Capacity | 820 Gbps |
| Stacking | • Stacking Number: 8 • Stacking Port: 25G SFP28 • Stack Bandwidth: Up to 300 Gbps (6 stack ports) |
| Tốc độ chuyển gói | 610.1 Mpps |
| Bảng địa chỉ MAC | 128 K |
| Bộ nhớ đệm gói | 8 MB |
| Khung Jumbo | 9 KB |
| KHÁC | |
| Sản phẩm bao gồm | • SX6632YF Switch • Power Cord • Quick Installation Guide • Rackmount Kit • Rubber Feet |
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. |
| Môi trường | • Operating Temperature: -5 °C to 50 °C (23 °F to 122 °F) @ 300 meters -5 °C to 45 °C (23 °F to 113 °F) @ 2,000 meters -5 °C to 40 °C (23 °F to 104 °F) @ 3,000 meters • Storage Temperature: -40 °C to 70 ℃ (-40 ℉ to 158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
| TP-Link SX6632YF | Omada Stackable L3 Managed Aggregation Switch 26 cổng 10G với 6 khe 25G |
|---|---|
| TÍNH NĂNG PHẦN MỀM | |
| Chất lượng dịch vụ | • Class of Service - 8 Queues of Priority - Port Priority - IEEE 802.1p Priority - DSCP Priority - Queue Min-Bandwidth - Schedule Mode (SP, WRR, SP+WRR) • Bandwidth Control - Rate Limit - Strom Control • User-Defined OUI • Smoother Performance • Action for Flows - QoS remark (802.1P Remark, DSCP Remark) |
| L3 Features | • IP Interfaces: - IPv4: Max 256, IPv6: Max 256 • Static Routing - IPv4: Max 2,048, IPv6: Max 1,024 • Host Route Table: Max 15,300 entries • RIP: Version v1/v2, Max 102,400 - RIPng: Max 51,200 • OSPF: Version v2/v3; - v2: Max 102,400 - v3: Max 51,200 • VRRP: Version v2/v3, Max 64 groups • ECMP: 256 entries, max 32 ECMP Nexhops per Destination • Static ARP - 1,024 static entries • Dynamic ARP - 24,576 dynamic entries • Proxy ARP • DHCP Server: - Max 64 IP Pools - Max 1,000 Manual Binding Entries • DHCP Relay: - Relayed Interface - Relayed VLAN |
| L2 and L2+ Features | • Link Aggregation - Static link aggregation - 802.3ad LACP - Up to 8 ports per group - Up to 120 LAG Groups • Spanning Tree Protocol - 802.1d STP - 802.1w RSTP - 802.1s MSTP - Up to 64 MSTI instances (4 at Omada controller mode) - STP Security: TC Protect, BPDU Filter, BPDU Protect, Root Protect, Loop Protect • Loopback Detection - Port based - VLAN based • Flow Control - 802.3x Flow Control • Supports 4,093 IGMP groups • ERPS: Up to 64 ERPS rings • Mirroring - Port Mirroring - CPU Mirroring - One-to-One - Many-to-One - Tx/Rx/Both • RSPAN • Mac Address - MAC Address Table - Static MAC: Max 128 entries - Dynamic MAC Address: Max 128K entries - Filtering MAC Address: Max 128 entries • Virtual MAC (only supported in standalone mode) • PIM-DM, PIM-SM (IPv4) |
| Advanced Features | • Automatic Device Discovery† • Batch Configuration† • Batch Firmware Upgrading† • Intelligent Network Monitoring† • Abnormal Event Warnings† • Unified Configuration† • Reboot Schedule† ISP Features: • 802.3ah Ethernet Link OAM • L2PT (Layer 2 Protocol Tunneling) • Device Link Detect Protocol (DLDP) • DDM • sFlow • PPPoE ID Insertion |
| VLAN | • VLAN Group (802.1q VLAN) - Max 4K VLAN Groups • 802.1Q Tagged VLAN • MAC VLAN entries: 200 • Multicast VLAN • Management VLAN • VLAN VPN (QinQ): Max 256 entries • GVRP • Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries • VLAN VPN - VLAN Mapping - VLAN Replace • Voice VLAN • Private VLAN |
| Bảo mật | • Port Isolation • CPU-Deffend • ARP Inspection (Dynamic ARP Inspection) • DoS Defend • IP-MAC-Port Binding -1,024 Entries - DHCP Snooping - ARP Inspection - IPv4 Source Guard • IPv6-MAC -Port Binding -1,024 Entries - DHCPv6 Snooping - ND Detection - ND Snooping - IPv6 Source Guard • DHCP Filter • Static/Dynamic Port Security - Up to 64 MAC addresses per port • Broadcast/Multicast/Unknown-unicast Storm Control - kbps/ratio control mode • 802.1X - Port base authentication - Mac base authentication - VLAN Assignment - MAB - Guest VLAN - Support RADIUS authentication and accountability • AAA (including TACACS+) • Secure web management through HTTPS with SSLv3/TLS 1.2 • Secure Command Line Interface (CLI) management with SSHv2 • IP/Port/MAC based access control |
| QUẢN LÝ | |
| Omada App | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Centralized Management | • Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller |
| Cloud Access | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller |
| Zero-Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller. |
| Management Features | • Web-based GUI • Command Line Interface (CLI) through console port, telnet • SNMPv1/v2c/v3 - Trap/Inform - RMON (1, 2, 3, 9 groups) • SDM Template • DHCP/BOOTP Client • 802.1ab LLDP/LLDP-MED • DHCP Auto Install • Dual Image, Dual Configuration • CPU Monitoring • Cable Diagnostics • Password Recovery • SNTP • System Log |
