Mô tả sản phẩm

Thiết bị tường lửa Firewall SonicWall NSA 5700 (02-SSC-4330)

Model	SonicWall NSA 5700 (02-SSC-4330)
Operating system	SonicOS 7
Interfaces	6 x 10G/5G/2.5G/1G (SFP+); 2x 10G/5G/2.5G/1G (Cu); 24 x 1GbE Cu 2 USB 3.0, 1 Console, 1 Mgmt. port
Storage	128GB
Expansion	Storage Expansion Slot (Up to 1TB)
VLAN interfaces	512
Access points supported (maximum)	512
Firewall/VPN Performance
Firewall inspection throughput	28 Gbps
Threat Prevention throughput	15 Gbps
Application inspection throughput	18 Gbps
IPS throughput	17 Gbps
Anti-malware inspection throughput	16 Gbps
TLS/SSL inspection and decryption throughput (DPI SSL)	7 Gbps
IPSec VPN throughput	15 Gbps
Connections per second	228,000
Maximum Connections (SPI)	5,000,000
MAX DPI-SSL Connections	350,000
Maximum connections (DPI)	3,500,000
VPN
Site-to-site VPN tunnels	6,000
IPSec VPN clients (max)	2000 (4000)
SSL VPN licenses (max)	2 (1500)
Encryption/Authentication	DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
Key exchange	Diffie Hellman Groups 1, 2, 5, 14v
Route-based VPN	RIP, OSPF, BGP
Certificate support	Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
VPN features	Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
Global VPN client platforms supported	Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Windows 10 Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit,
NetExtender	Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, B5Linux FC3+/Ubuntu 7+/OpenSUSE
Mobile Connect	Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Chrome, Windows 8.1 (Embedded)
Security services
Deep Packet Inspection services	Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
Content Filtering Service (CFS)	HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Firewall
Comprehensive Anti-Spam Service	Supported
Application Visualization	Yes
Application Control	Yes
Capture Advanced Threat Protection	Yes
Networking
IP address assignment	Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
NAT modes	1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
Routing protocols	BGP4, OSPF, RIPv1/v2, static routes, policy-based routing
QoS	Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
Authentication	LDAP (multiple domains), XAUTH/RADIUS, TACACS+, SSO, Radius accounting NTLM, internal user database, 2FA, Terminal Services, Citrix, Common Access Card (CAC)
Local user database	2500
VoIP	Full H323-v1-5, SIP
Standards	TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications (pending)	FIPS 140-2 (with Suite B), UC APL, IPv6 (Phase 2), ICSA Network Firewall, ICSA Anti-virus, Common Criteria NDPP (Firewall and IPS)
Common Access Card (CAC)	Supported
High availability	Active/Passive with stateful synchronization
Hardware
Form factor	1U Rack Mountable
Fans	2
Power supply	350W
Maximum power consumption (W)	128.1
Redundant Power Supply	100-240 VAC, 50-60 Hz
Total heat dissipation	436.82 BTU
Dimensions	43 x 46.5 x 4.5 (cm) 16.9 x 18.1 x 1.8 in
Weight	7.8 Kg
WEEE weight	9.6 Kg
Shipping weight	13.5 Kg
Environment (Operating/Storage)	32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
Humidity	0-90% R.H non-condensing
Regulatory
Regulatory model numbers	1RK53-116
Major regulatory compliance	FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI
