NAS QNAP TS-1683XU-RP - 16-Bay, Intel® Xeon® E-2124 4 cores/4 threads 3.3 GHz processor (burst up to 4.3 GHz), 16 GB DDR4 ECC RAM (2 x 8 GB); redundant power supply ● 16-bay 3.5-inch SATA 6Gb/s, 3Gb/s ● 4 x GbE (RJ45), 2 x 10GbE SFP+ ● 6 x USB 3.2 Gen 2, 4 x PCIe expansion slot ● 2 x 500W, 100-240V power supply
Thiết bị lưu trữ NAS QNAP TS-1683XU-RP
| SKU | TS-1683XU-RP-E2124-16G | ||
|---|---|---|---|
| CPU | ● Intel® Xeon® E-2124 4-core 3.3 GHz processor (burst up to 4.3 GHz) ● Architecture: 64-bit x86 ● Floating Point Unit: Yes ● Encryption Engine: AES-NI |
||
| Memory | ● System: 16 GB UDIMM DDR4 ECC (2 x 8GB) ● Maximum: 128 GB (4 x 32 GB) ● Slot: 4 x UDIMM DDR4 |
||
| Flash Memory | 5GB (Dual boot OS protection) | ||
| Drive Bay | 16 x 3.5-inch SATA 6Gb/s, 3Gb/s | ||
| Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
||
| Hot-swappable | Yes | ||
| SSD Cache Acceleration Support | Yes | ||
| Gigabit Ethernet Port (RJ45) | 4 | ||
| 10 Gigabit Ethernet Port | 2 x 10GbE SFP+ SmartNIC port | ||
| PCIe Slot | 4 Slot 1: PCIe Gen 2 x4 (PCH) Slot 2: PCIe Gen 3 x8 (CPU) Slot 3: PCIe Gen 3 x4 (CPU) Slot 4: PCIe Gen 3 x4 (CPU) |
||
| USB 3.2 Gen 2 (10Gbps) Port | 2 x Type-C USB 3.2 Gen 2 10Gbps 4 x Type-A USB 3.2 Gen 2 10Gbps |
||
| Form Factor | 3U Rackmount | ||
| LED Indicators | HDD 1-16, Status, LAN, storage expansion port status | ||
| Buttons | Power, Reset | ||
| Dimensions (HxWxD) | 130 × 481 × 573.5 mm | ||
| Weight | 13.76 kg ~ 21.79 kg | ||
| Operating temperature | 0 - 40 °C (32°F - 104°F) | ||
| Storage Temperature | -20 - 70°C (-4°F - 158°F) | ||
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) | ||
| Power supply unit | 500W(x2), 100-240V | ||
| Power Consumption: Operating Mode, Typical | 130.43 W | ||
| Fan | System fan: 3 x 80mm, 12VDC | ||
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 10000 | ||
16-Bay NAS, Intel® Xeon® E-2124 quad-core 3.3 GHz processor (burst up to 4.3 GHz), 16 GB UDIMM DDR4 (2 x 8GB)
|
