8 x 10/100/1000 Mbps RJ-45 ports
1 x 10/100/1000 out-of-band management port, 1 x RJ45 console port, 2 x USB port, 1 x Micro USB console port
5.1/4.4 Gbps Firewall throughput (HTTP/appmix)
2.1/2.4 Gbps Threat Prevention throughput (HTTP/appmix)
3.0 Gbps Gbps IPsec VPN throughput
400,000 Max sessions
73,000 New sessions per second.

Thiết bị tường lửa Palo Alto Networks PA-460

SKU	PAN-PA-460
Performance and Capacities
Firewall throughput (HTTP/appmix)	5.1/4.4 Gbps
Threat Prevention throughput (HTTP/appmix)	2.1/2.4 Gbps
IPsec VPN throughput	3.0 Gbps
Max sessions	400,000
New sessions per second	73,000
Hardware Specifications
I/O	10/100/1000 (8) RJ45
Management I/O	10/100/1000 out-of-band management port (1) RJ45 console port (1) USB port (2) Micro USB console port (1)
Storage Capacity	128 GB SSD
Power Supply (Avg/Max Power Consumption)	33/41 W
Max BTU/hr	141
Input Voltage (Input Frequency)	100–240 VAC (50–60Hz)
Max Current Consumption	3.4 A @ 12 VDC
Max Inrush Current	4.2 A
Dimensions	1.74” H x 8.83” D x 8.07” W
Weight (Standalone Device/As Shipped)	5.0 lbs / 7.8 lbs
Safety	cTUVus, CB
EMI	FCC Class B, CE Class B, VCCI Class B
Environment	Operating temperature: 32° to 104° F, 0° to 40° C Non-operating temperature: -4° to 158° F, -20° to 70° C Passive cooling

PA-400 Series Networking Features
Interface Modes	L2, L3, tap, virtual wire (transparent mode)
Routing	OSPFv2/v3 with graceful restart, BGP with graceful restart, RIP, static routing Policy-based forwarding Point-to-Point Protocol over Ethernet (PPPoE) Multicast: PIM-SM, PIM-SSM, IGMP v1, v2, and v3
SD-WAN	Path quality measurement (jitter, packet loss, latency) Initial path selection (PBF) Dynamic path change
IPv6	L2, L3, tap, virtual wire (transparent mode) Features: App-ID, User-ID, Content-ID, WildFire, and SSL Decryption SLAAC
IPsec VPN	Key exchange: manual key, IKEv1, and IKEv2 (pre-shared key, certificate-based authentication) Encryption: 3DES, AES (128-bit, 192-bit, 256-bit) Authentication: MD5, SHA-1, SHA-256, SHA-384, SHA-512
VLANs	802.1Q VLAN tags per device/per interface: 4,094/4,094

PA-400 Series Hardware
Palo Alto Networks PA-460	#PAN-PA-460
PA-460 - Bundle Subscriptions for 36 months
PA-460, Threat prevention subscription, 3 years (36 months), term	#PAN-PA-460-TP-3YR
PA-460, PAN-DB URL Filtering subscription, 3 years (36 months), term.	#PAN-PA-460-URL4-3YR
PA-460, WildFire subscription, 3 years (36 months), term.	#PAN-PA-460-WF-3YR
PA-460, DNS security subscription, 3 years (36 months), term.	#PAN-PA-460-DNS-3YR
PA-460, IoT subscription, 3 years (36 months), term.	#PAN-PA-460-IOT-3YR
PA-460, DLP subscription, 3 years (36 months), term.	#PAN-PA-460-DLP-3YR
SaaS Inline subscription, 3-year prepaid, PA-460	#PAN-PA-460-SAAS-INLINE-3YR

Extends native protection across all attack vectors with cloud-delivered security subscriptions

Threat Prevention — goes beyond a traditional intrusion prevention system (IPS) to prevent all known threats across all traffic in a single pass without sacrificing performance.
Advanced URL Filtering — provides best-in-class web protection while maximizing operational efficiency with the industry’s first real-time web protection engine and industry-leading phishing protection.
WildFire® — ensures files are safe with automatic detection and prevention of unknown malware powered by industry-leading cloud-based analysis and crowdsourced intelligence from more than 42,000 customers.
DNS Security — harnesses the power of ML to detect as well as prevent threats over DNS in real time and empowers security personnel with the intelligence and context to craft policies and respond to threats quickly and effectively.
IoT Security — provides the industry’s most comprehensive IoT security solution, delivering ML-powered visibility, prevention, and enforcement in a single platform.
Enterprise DLP — offers the industry’s first cloud-delivered enterprise DLP that consistently pro-tects sensitive data across networks, clouds, and users.
SaaS Security — delivers integrated SaaS security that lets you see and secure new SaaS applica-tions, protect data, and prevent zero-day threats at the lowest total cost of ownership (TCO).
