Thiết bị cân bằng tải Load Balancer A10 TH4430-010
| PERFORMANCE | |
| Application Throughput (L4/L7) | 38 Gbps / 38 Gbps |
| Layer 4 CPS | 2.7 Million |
| Layer 4 HTTP RPS | 12 Million |
| Layer 4 Concurrent Sessions | 128 Million |
| Layer 7 CPS (1:1) | 620K |
| SSL Bulk Throughput | 20 Gbps |
| SSL CPS | RSA (1K): 86K RSA (2K): 84K |
| DDoS Protection (SYN Flood) SYN/sec | 55 Million |
| Application Delivery Partitions (ADP) | 127 |
| NETWORK INTERFACE | |
| 1 GE Copper | 0 |
| 1 GE Fiber (SFP) | 0 |
| 1/10 GE Fiber (SFP+) | 16 |
| 40 GE Fiber (QSFP+) | 4 |
| Management Ports | 1 x Ethernet Mgmt port, 1 x RJ-45 console port, 1 x Lights Out Management |
| HARDWARE SPECIFICATIONS | |
| Processor | Intel Xeon 6-core |
| Memory (ECC RAM) | 32 GB |
| Storage | SSD |
| Hardware Acceleration | FTA-3 |
| SSL Security Processor ('S' Models) | Yes |
| Dimensions (inches) | 1.75 (H) x 17 (W) x 24.6 (D) |
| Rack Units (Mountable) | 1U |
| Unit Weight | 25.2 lbs |
| Power Supply (DC option available) | Dual 600W RPS 80 Plus Platinum efficiency, 100 - 240 VAC, 50 – 60 Hz |
| Power Consumption (Typical/Max) | 266W / 319W |
| Heat in BTU/hour (Typical/Max) | 908 / 1,088 |
| Cooling Fan | Hot Swap Smart Fans |
| Operating Ranges | Temperature 0° - 40° C | Humidity 5% - 95% |
| Regulatory Certifications | FCC Class A, UL, CE, TUV, CB, VCCI, CCC, KCC, BSMI, RCM, NEBS | RoHS, CC EAL2+ |
Mã đặt hàng
| Part Number | Mô tả |
| TH4430-010 | Thunder 4430 ADC, 1U, 1x CPU, 4x 40GF, 16x 10GF, 32GB, SSD, LOM, 1x FTA/FPGA, S+R ASIC, No H/W SSL |
| TH4430-010-4SSL | Thunder 4430S ADC, 1U, 1x CPU, 4x 40GF, 16x 10GF, 32GB, SSD, LOM, 1x FTA/FPGA, S+R ASIC, Quad Chip H/W SSL |
| TH4430-010-SSL | Thunder 4430S ADC, 1U, 1x CPU, 4x 40GF, 16x 10GF, 32GB, SSD, LOM, 1x FTA/FPGA, S+R ASIC, Dual Chip H/W SSL |
| TH4430-010-SSL-FIPS | Thunder 4430S ADC, 1U, 1x CPU, 4x 40GF, 16x 10GF, 32GB, SSD, LOM, 1x FTA/FPGA, S+R ASIC, H/W SSL, FIPS-validated |
| TH4430-D10 | Thunder 4430 ADC, 1U, 1x CPU, 4x 40GF, 16x 10GF, 32GB, SSD, LOM, 1x FTA/FPGA, S+R ASIC, No H/W SSL DC Power |
| TH4430-D10-4SSL | Thunder 4430S ADC, 1U, 1x CPU, 4x 40GF, 16x 10GF, 32GB, SSD, LOM, 1x FTA/FPGA, S+R ASIC, Quad Chip H/W SSL, DC Power |
| TH4430-D10-SSL | Thunder 4430S ADC, 1U, 1x CPU, 4x 40GF, 16x 10GF, 32GB, SSD, LOM, 1x FTA/FPGA, S+R ASIC, Dual Chip H/W SSL DC Power |
