Huawei eKitEngine S310-24P4S Layer 2 Managed Switch :
Thiết bị chuyển mạch Switch Huawei eKitEngine S310-24P4S
Model | S310-24P4S |
Switching capacity | • 56Gbps |
Packet forwarding | • 42Mpps |
Fixed port | • 24 x 10/100/1000BASE-T PoE+ ports, 4 x GE SFP ports |
Chassis dimensions (width x depth x height mm) | • 43.6 mm x 442 mm x 220 mm |
Chassis height | • 1 U |
Full weight | • 3.79 kg (including packaging materials) • 2.92 kg (excluding packaging materials) |
Power supply type | • Built-in AC power supply |
Rated voltage | • 100-240V AC; 50/60 Hz |
Maximum voltage | • AC input: 90-290V AC, 45-65 Hz |
Maximum power consumption | • Without PoE: 43.6 W • With PoE: 488.6 W (PoE: 400W) |
Noise | • Sound power at normal temperature: 49.3 dB (A) • Sound power at high temperature: 63 dB (A) • Sound pressure at normal temperature: 37.3 dB (A) |
Long term operating temperature | • –5°C to +50°C (0 m to 1800 m) • When the altitude ranges between 1800 m and 5000 m, the operating temperature reduces by 1°C each time the altitude increases by 220 m. |
Storage temperature | • -40°C ~ +70°C |
Relative humidity | • 5% ~ 95% (no condensation) |
Business port lightning protection | • Common mode ±10 kV |
Lightning protection for power port | • Differential mode: ± 6 kV • Common mode: ± 6 kV |
Heat dissipation method | • Air cooling, intelligent speed regulation |
