Trang chủ > Sản phẩm > Thiết bị mạng Fortinet > Firewall FortiGate > FortiGate 71F UTP 1 Year (FG-71F-BDL-950-12)

FortiGate 71F UTP 1 Year (FG-71F-BDL-950-12)

FG-71F-BDL-950-12 thiết bị tường lửa Fortinet FortiGate 71F Hardware Plus Forticare Premium and FortiGuard UTP - 1 Year Subscription

  • Recommended: for 51-100 User Network
  • Ports: 10 x GE RJ45 (including 7 x Internal Ports, 2 x WAN Ports, 1 x DMZ Port)
  • Threat Protection Throughput: 800 Mbps
  • Site-to-Site VPN Tunnels: 200
  • Concurrent Sessions: 1,500,000
  • FortiCare Premium and FortiGuard Unified Threat Protection (UTP) - 1 Year Subscription
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng

Thiết bị tường lửa Firewall Fortinet FortiGate-71F (FG-71F-BDL-950-12)

Mã sản phẩm FG-71F-BDL-950-12
Hardware Specifications
GE RJ45 WAN / DMZ Ports 2 / 1
GE RJ45 Internal Ports 5
GE RJ45 FortiLink Ports (Default) 2
USB Ports 1
Console (RJ45) 1
Internal Storage  1 x 128 GB SSD
Trusted Platform Module (TPM) No
Bluetooth Low Energy (BLE) No
System Performance — Enterprise Traffic Mix
IPS Throughput 1.4 Gbps
NGFW Throughput 1 Gbps
Threat Protection Throughput 800 Mbps
System Performance
Firewall Throughput (1518 / 512 / 64 byte UDP packets)  10/10/6 Gbps
Firewall Latency (64 byte UDP packets)  2.54 μs
Firewall Throughput (Packets Per Second)  9 Mpps
Concurrent Sessions (TCP)  1.5 M
New Sessions/Second (TCP)  35 000
Firewall Policies  5 000
IPsec VPN Throughput (512 byte) 6.1 Gbps
Gateway-to-Gateway IPsec VPN Tunnels  200
Client-to-Gateway IPsec VPN Tunnels  500
SSL-VPN Throughput  405 Mbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)  200
SSL Inspection Throughput (IPS, avg. HTTP) 700 Mbps
SSL Inspection CPS (IPS, avg. HTTPS) 500
SSL Inspection Concurrent Session (IPS, avg. HTTPS) 100,000
Application Control Throughput (HTTP 64K) 1.8 Gbps
CAPWAP Throughput (HTTP 64K)  8.5 Gbps
Virtual Domains (Default / Maximum)  10 / 10
Maximum Number of FortiSwitches Supported  16
Maximum Number of FortiAPs (Total / Tunnel Mode)  64 / 32
Maximum Number of FortiTokens  500
High Availability Configurations  Active / Active, Active / Passive, Clustering
Height x Width x Length (inches)  1.5 x 8.5 x 6.3
Height x Width x Length (mm)  38.5 x 216 x 160 mm
Weight  2.23 lbs (1.01 kg)
Form Factor  Desktop
Operating Environment and Certifications
Power Rating 12VDC, 3A
Power Required  Powered by External DC Power Adapters, 100–240V AC, 50/60 Hz
Maximum Current 100VAC/1.0A, 240VAC/0.6A
Power Consumption (Average / Maximum)  17.2 W / 18.7 W
Heat Dissipation  63.8 BTU/hr
Operating Temperature  32–104°F (0–40°C)
Storage Temperature  -31–158°F (-35–70°C)
Humidity  10–90% non-condensing
Noise Level Fanless 0 dBA
Operating Altitude Up to 7,400 ft (2,250 m)
Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN

Các phụ kiện và Module dùng với FortiGate 71F

Accessories SKU Description
Rack Mount Tray SP-RACKTRAY-02 Rack mount tray for all FortiGate E series and F series desktop models are backwards compatible with SP-RackTray-01
AC power adaptor SP-FG60E-PDC-5 Pack of 5 AC power adaptors for G/FWF 60E/61E, FG/FWF 60F/61F, FG-70F/71F, and FG-80E/81E
Wall Mount Kit SP-FG60F-MOUNT-20 Pack of 20 wall mount kits for G/FWF-60F, FG-70F/71F and FG/FWF-80F series

Hardware Plus Forticare Premium and Fortiguard UTP - 1 Year Subscription (FG-71F-BDL-950-12)
- Hardware: 10x GE RJ45 ports (including 7x Internal ports, 2x WAN ports, 1x DMZ port), 128 GB SSD onboard storage.
- 1 Year Hardware plus 24x7 FortiCare Premium Ticket Handling, Advanced Hardware Replacement (NBD), Firmware and General Upgrades, UTP Services Bundle (IPS, AV, Botnet IP/Domain, Mobile Malware, FortiGate Cloud Sandbox including Virus Outbreak and Content Disarm & Reconstruct, Application Control, Web & Video Filtering and Antispam Service)

Data sheet Firewall Fortinet FortiGate 70F Series
