Thiết bị wireless Dlink DWL-X8630AP
| Model | DWL-X8630AP |
| General | |
| Wireless Interface | • IEEE 802.11a/b/g/n/ac/ax (Wi-Fi 6) |
| MIMO | • 4 x 4 |
| Data Rate2 | • 2.4 GHz - Up to 1147 Mbps (1024QAM) • 5 GHz - Up to 2402 Mbps (1024QAM) |
| Antenna | • Internal omni-directional antennas • 2.4 GHz: 3 dBi • 5 GHz: 4 dBi |
| Operating Frequency | • 2400 to 2483.5 MHz • 5150 to 5850 MHz |
| Operating Channels | • 1 to 13 channels for 2.4 GHz band (per country code) • 36 to 165 channels for 5 GHz band (per country code) |
| Ethernet Interface | • 1 x 10/100/1000 BASE-T LAN port • 1 x 10/100/1000/2500 BASE-T LAN port |
| Console Port | • RJ-45 |
| Functionality | |
| Advanced Features | • Auto Channel selection • 802.1p Quality of Service (QoS) • Wireless Multimedia (WMM) • Wireless Distribution System (WDS) • Band steering • Airtime Fairness • Link Aggregation3 • IEEE 802.11k Fast Roaming |
| Management | |
| Operating Mode | • Standalone mode • Managed mode - Centrally managed by D-Link Wireless Controller |
| Management Interfaces | • Web-based User Interface (Web UI) • Telnet/SSH • Command Line Interface (CLI) • SNMP v1/v2c/v3 |
| Security | |
| SSID Security | • Up to 32 SSIDs, 16 per radio • 802.1Q VLAN • Station Isolation |
| Wireless Security | • Latest 128-bit Personal wireless encryption • Latest 192-bit Enterprise wireless encryption • SAE • OWE (Enhanced Open) • AES • TKIP |
| Detection & Prevention | • Rogue and Valid AP Classification |
| Authentication | • MAC Address Filtering |
| Physical | |
| Dimensions | • 220 x 47 mm (8.66 x 1.97 in) |
| Weight | • 0.868 kg (1.91 lbs) without bracket • 0.889 kg (1.96 lbs) with bracket |
| Power Supply | • External Power Adapter: 12 VDC 2.5A • Supports 802.3at PoE PD on LAN 1 Port |
| Power over Ethernet | • 802.3at |
| Maximum Power Consumption | • 19.98 W |
| Enclosure | • Bottom cover - plastic • Top cover - plastic • UL2043 certified chassis |
| Temperature | • Operating: 0 to 40 °C (32 to 104 °F) • Storage: -20 to 65 °C (-4 to 149 °F) |
| Humidity | • Operating: 10% to 90% non-condensing • Storage: 5% to 95% non-condensing |
| MTBF | • 485,222 hours |
