D-Link DSS-100E-26P 26 Port Unmanaged PoE Surveillance Switch :
Thiết bị chuyển mạch Switch D-Link DSS-100E-26P
| Model | DSS-100E-26P |
| General | |
| Size | • 19” standard rack width, 1U height |
| Interfaces | • 24 x 10/100BASE-T PoE ports • 1 x 1000BASE-T ports • 1 x 100/1000BASE-T/SFP combo port |
| Standards | • IEEE 802.3 100BASE-T Ethernet • IEEE 802.3u 100BASE-TX Fast Ethernet • IEEE802.3ab • IEEE 802.3z • IEEE 802.3x Flow Control |
| Media Interface Exchange | • Auto or configurable MDI/MDIX |
| LED | • Per unit: Power • Per port: Activity / Link and Speed • Per PoE port: Power fail, Power OK |
| Functionality | |
| Switching Capacity | • 8.8 Gbps |
| Forwarding Rate | • 6.55 Mpps |
| Packet Buffer | • 4.0 Mbits |
| Transmission Method | • Store-and-Forward |
| MAC Address Table Size | • 16K |
| Static MAC Addresses | • Up to 512 static MAC entries |
| Maximum Forwarding Rate | • 139.88 Mpps |
| PoE Standard | • IEEE802.3at, IEEE802.3af |
| PoE Power Budget | • 230 W |
| Surge Protection | • Up to 6 kV |
| Physical | |
| Power Input | • 100 - 240 VAC |
| Maximum Power Consumption | • PoE ON: - AC: 269.28 W - DC: 239.57 W • PoE OFF: - AC: 14.84 W - DC: 8.92 W |
| Standby Power Consumption | • 100V: 9.12 W • 240V: 9.18 W |
| Acoustics | • 35.3 dB(A) |
| Heat Dissipation | • Power On: 6.91 BTU/h • Maximum: 29.71BTU/h |
| MTBF | • 402,625 hours |
| Operating Temperature | • 0 - 40 °C |
| Storage Temperature | • -40 - 70°C |
| Operating Humidity | • 10% - 95% RH |
| Storage Humidity | • 5% - 95% RH |
