Dây nhảy LS cáp Cat 6A chống nhiễu, đầu đúc, vỏ PVC, 1m, xx (LS-PC-SC6A-xx-010-M) - Shielded Cat 6A Patch Cord, Molding type, PVC jacket, 1m, xx
LS Shielded Cat 6A Patch Cord, Molding type, PVC jacket, 1m, xx (LS-PC-SC6A-xx-010-M)
Part number: LS-PC-SC6A-xx-010-M.
- Category 6A Shielded Patch Cord with T568B Wiring.
- Chiều dài dây: 1 mét.
- Lõi cáp mềm.
- Chất liệu vỏ: Nhựa PVC.
- Horizontal Distribution & Backbone Cabling.
- 4/16 Mbps Token Ring (IEEE 802.5).
- 10/100/1000/10G BASE-T (IEEE 802.3).
- 155 Mbps ATM.
- 100Mbps TP-PMD.
- ISDN, ADSL.
- RoHS Compliant.
- ATM LAN 1.2G.
Đặc tính kỹ thuật
| Part Number | LS-PC-SC6A-xx-010-M |
| Electrical / Mechanical Characteristics | |
| Current Rating | 1.5 A |
| Contact Resistance | 20 mΩ |
| Insulation Resistance | 500 MΩ Max |
| Dielectric Strength | 100 VAC (RMS) |
| Voltage | 30 VAC Max |
| Insertion Life | 750 Mating Cycles |
| Plug Retention Force | 20 lbs (89N) |
| Temperature | -20ºC ~ 68ºC |
| Humidity | 10% ~ 90% RH |
| IDC Accept | 22 ~ 26 AWG Solid Wire |
| Materials | |
| Plug Housing | Polycarbonate, UL 94V-2 Rated |
| Contact Blade | Phosphor Bronze Plated with 50 Micro-inch (1.27 microns) Thick Gold Over 100 Micro-inch (2.54 microns) Thick Nickel Undercoat |
| Cable Jacket | PVC |
| Approvals | |
| Category | TIA/EIA-568-B.2-10 Category 6A / ISO 11801 Category EA |
| Wiring Scheme | T568B |
| Meet | FCC CFR 47 Parts 68 and IEC 603-7 |
Sản xuất tại Việt Nam
| LS-PC-SC6A-xx-010-M | Dây nhảy cáp Cat 6A chống nhiễu, đầu đúc, vỏ PVC, 1m, xx Shielded Cat 6A Patch Cord, Molding type, PVC jacket, 1m, xx |
