CS-BOARD70S-G-K9 Cisco Webex Board 70S. Thiết bị hội nghị truyền hình All-in-one CISCO Webex Board 70S CS-BOARD70S-G-K9: ● Tích hợp bộ xử lý trung tâm, microphone, loa, camera, màn hình cảm ứng chuyên dụng ● Bộ thiết bị hội nghị truyền hình tích hợp màn hình cảm ứng 4K ● Kích thước màn hình: 70 inch, tỷ lệ 16:9 ● Chuẩn video full HD kết nối với Cisco Collaboration Cloud ● Tích hợp 12 micro tự động bắt hình và speaker chất lượng cao ● Tích hợp camera 4K, fixed lens ● Góc mở camera: 83° ● Kết nối: 1 HDMI input/1 Audio output ● Hỗ trợ kết nối wi-fi, bluetooth.
Thiết bị hội nghị truyền hình Cisco Webex Board 70S (CS-BOARD70S-G-K9)
| Mã sản phẩm | CS-BOARD70S-G-K9 |
| Software | Cisco Webex Room OS, provisioned and updated automatically by Cisco Webex in the cloud |
| Components | Fully integrated unit is delivered with: |
| ● Multi-touch 70-inch LED display | |
| ● 4K camera | |
| ● 12-microphone array | |
| ● Speakers | |
| ● White boarding pen | |
| Display | ● Edge LED LCD – 70-inch 4K, 300 nits, 16:9 |
| ● Viewing angle: +- 88 degrees (all directions) | |
| ● Number of colors: 1.07 billion (10 bit) | |
| ● Contrast: 1:4000 | |
| ● Response time: 6 ms | |
| User interface | ● Capacitive touch |
| ● Protective glass with optical bonding | |
| ● Multi-touch | |
| Inputs and outputs | ● HDMI input |
| ● Home button | |
| ● 3.5-mm mini jack audio out (line out) | |
| ● USB micro (service) | |
| ● USB-C (future use) | |
| Camera overview | ● Fixed lens, infinite focus |
| ● F-value: 2.8 | |
| ● 4Kp60 | |
| ● Horizontal field of view (HFOV): 83 degrees | |
| ● Vertical field of view (VFOV): 55 degrees | |
| ● Camera mounted tilted: -25 degrees | |
| Audio system | ● 12-element microphone array (with intelligent voice tracking) |
| ● Integrated voice-optimized speakers | |
| Network | ● Ethernet (RJ-45) 100/1000 Mbps |
| ● Wi-Fi 802.11a/b/g/n; 802.11ac (2.4 and 5 GHz) | |
| ● IPv4 Dynamic Host Configuration Protocol (DHCP)/static | |
| ● IPv6 (both static and stateless address auto-configuration) | |
| ● Network Time Protocol (NTP) | |
| ● HTTP(S) Proxy support (for signaling, not media) | |
| ● Inspecting TLS Proxy supported | |
| ● Cisco Discovery Protocol (CDP) | |
| ● 802.1X network authentication (Passphrase or X.509 client certificate) | |
| ● 802.1Q virtual LAN | |
| ● 802.1p (Qos and Class of Service [CoS]) | |
| User controls | ● Control Cisco Webex Board directly from the touchscreen or using the Cisco Webex Teams app |
| Language support | ● English, Spanish, German, French, French Canadian, Portuguese, Japanese, Czech, Danish, Dutch, Norwegian, Swedish, Latin American Spanish, Italian, Finnish, Polish, Turkish |
| ● Additional languages to be supported in future software release | |
| Physical dimensions (H x W x D) | ● 40.7 x 64.1 x 2.4 in (1034 x 1627 x 61 mm) |
| Weight | ● 141.8 lb (64.3 kg) |
| Physical dimensions and weight of packaging (H x W x D) | Main unit |
| ● Consolidated package size: 47.5 x 73.8 x 9.6 in (1207 x 1875 x 245 mm) | |
| ● Weight: 141.8 lb (64.3 kg) | |
| ● Shipping weight (including packaging): 159.4 lb (72.3 kg) | |
| Wall mount | |
| ● Consolidated package size: 10.1 x 66 x 3.6 in (256 x 1675 x 92 mm) | |
| ● Weight: 13.2 lb (6 kg) | |
| ● Shipping weight: 15.4 lb (7 kg) | |
| Floor stand | |
| ● Consolidated package size: 60 x 47 x 6.7 in (1524 x 1186 x 172 mm) | |
| ● Weight: 33 lb (15 kg) | |
| ● Shipping weight: 37.5 lb (17 kg) | |
| Wall Stand | |
| ● Consolidated package size: 64.7 x 45.8 x 4.6 in (1643 x 1164 x 116 mm) | |
| ● Weight: 28.7 lb (13 kg) | |
| ● Shipping weight: 39.7 lb (18 kg) | |
| Cisco Webex Board and the selected mounting option will be shipped in a consolidation pack on a pallet. The dimensions above describe each of the individual boxes within the consolidation packaging. | |
| Power | ● Autosensing power supply |
| ● 100 to 240 VAC, 50 to 60 Hz | |
| ● Power consumption (Max 4.6A): | |
| ◦ Sleep: 33W | |
| ◦ Idle or in-use: 222W | |
| System management | Cisco Webex Board is managed in the administrator portal in Cisco Webex, giving system status and overview, activation, configuration, metrics, and troubleshooting. |
| Operating temperature and humidity | ● 0° to 35°C (32° to 95°F) at relative humidity 10% to 90% (noncondensing) |
| Approvals and compliance | Regulatory compliance |
| ● Directive 2014/30/EU (EMC Directive) | |
| ● Directive 2014/53/EU (Radio Equipment Directive) | |
| ● Directive 2011/65/EU (RoHS) | |
| ● Directive 2002/96/EU (WEEE) | |
| ● NRTL approved (Product Safety) | |
| ● FCC Listed (Radio Equipment) | |
| Standards | |
| ● Radio: EN 300 328, EN 301 893, EN 300 440 | |
| ● EMC: EN 301 489-1 & -17, EN 55032 - Class A, EN 55024 | |
| ● Safety: EN 60950-1, EN 62479, EN 62311 (for the radio versions) | |
| ● FCC CFR 47 Part 15B (EMC) - Class A | |
| ● FCC CFR 47 Part 15C (RF) | |
| ● FCC CFR 47 Part 15E (R) | |
| Please check product approval status database https://www.ciscofax.com for approval documents per country. | |
| System requirements | ● Cisco Webex Board is connected to Cisco Webex using RESTful APIs. Communication with other Webex Boards, Webex Teams apps, or other third-party solutions is provided through Cisco Webex platform |
| ● Communication with Cisco Webex uses the H.264 codec for video and the OPUS codec for audio | |
| ● Real-time media (voice, video, and screen sharing) is encrypted using the Secure Real-Time Transport Protocol (SRTP); end-to-end encryption uses Advanced Encryption Standard (AES) 128, AES 256, SHA1, SHA256, and RSA | |
| Bandwidth requirements | Minimum bandwidth: |
| ● 720p30 from 768 Kbps | |
| ● 1080p30 from 1.72 Mbps | |
| Maximum bandwidth: | |
| ● Transmit: 4.3 Mbps | |
| ● Receive: 10 Mbps | |
| Video inputs | ● 1 HDMI for local presentation or sharing in meetings |
| ● Supports formats up to maximum 4K (3840 x 2160) | |
| ● Frame rate of 60 fps for up to 1080p and 30 fps for 2160p | |
| ● Extended Display Identification Data (EDID) | |
| Presentation capabilities | ● Local presentation up to 4K |
| ● Audio over HDMI | |
| Live video resolutions (encode/decode) | Main video: |
| ● Up to 1920 x 1080@30 (HD1080p) | |
| Presentation sharing: | |
| ● Up to 1920 x 1080@30 (HD1080p) | |
| Audio features | ● High-quality 20-kHz audio |
| ● Acoustic echo cancellation | |
| ● Automatic Gain Control (AGC) | |
| ● Automatic noise reduction | |
| ● Active lip synchronization | |
| ● Microphone array with intelligent voice tracking capabilities |
