Thiết bị mạng Switch Cisco C9500-40X-2Q-E
Part Number | C9500-40X-2Q-E |
Product Description | Catalyst 9500 40 x 10G, 2 x 40G Bundle, Network Essentials |
Switching capacity | Up to 960 Gbps full duplex |
Forwarding rate | Up to 720 Mpps |
Total number of MAC addresses | Up to 64,000 |
Total number of IPv4 routes (Address Resolution Protocol [ARP] plus learned routes) | Up to 64,000 indirect |
Up to 80,000 host* | |
Total number of IPv6 routes | Up to 32,000 indirect |
Up to 40,000 host | |
Multicast scale | Up to 16,000 |
QoS ACL scale | Up to 18000 |
Security ACL scale | Up to 18000 |
FNF entries | Up to 512,000 |
DRAM | 16 GB |
Flash | 16 GB |
VLAN IDs | 4000 |
Total Switched Virtual Interfaces (SVIs) | 4000 |
Jumbo frame | 9216 bytes |
Dimensions (H x W x D) | 1.73 x 17.5 x 21.52 in |
Rack Units (RU) | 1 RU |
Chassis with 2 power supplies and built-In fan | 25.75 lb (11.68 kg) |
Input voltage | 115 to 230 VAC |
Operating temperature | 32° to 104°F (0° to 40°C) |
Storage temperature | -4° to 149°F (-20° to 65°C) |
Relative humidity operating and nonoperating noncondensing |
Ambient (noncondensing) operating: 5% to 90% |
Ambient (noncondensing) nonoperating and storage: 5% to 95% | |
Altitude | Operation up to 13,000 feet at 40°C |
MTBF (hours) | 277,310 |
