Trang chủ > Sản phẩm > Thiết bị mạng Cisco > Wireless Cisco > Cisco AIR-AP1832I-S-K9

Cisco AIR-AP1832I-S-K9

AIR-AP1832I-S-K9 - Cisco Aironet 1832i Access Point, 802.11ac Wave 2 AP, 3x3:2, Internal Antenna, S Regulatory Domain, is ideal for small and medium-sized networks.
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng


Thiết bị phát sóng Wifi Indoor Cisco AIR-AP1832I-S-K9

Part Number AIR-AP1832I-S-K9

Description

802.11ac Wave 2 AP, 3x3:2, Internal Antenna, S Regulatory Domain

Software

Cisco Unified Wireless Network Software Release with AireOS wireless controllers:

  • 8.1.121.0 or later for the Cisco Aironet 1830 Series Access Points

Deployment modes

Centralized, standalone, sniffer, Cisco FlexConnect, monitor, OfficeExtend, mesh

Supported wireless LAN controllers

  • Cisco 2500 Series Wireless Controllers, Cisco Wireless Controller Module for ISR G2, Cisco Wireless Services Module 2 (WiSM2) for Cisco Catalyst®6500 Series Switches, Cisco 5500 Series Wireless Controllers, Cisco 5520 Series Wireless Controllers, Cisco Flex® 7500 Series Wireless Controllers, Cisco 8500 Series Wireless Controllers, Cisco 8540 Series Wireless Controllers, Cisco 5760 Wireless LAN Controller, Cisco Catalyst 3650 and 3850 Series Switches with integrated controller
  • Cisco Mobility Express

802.11n version 2.0 (and related) capabilities

  • 3x3 MIMO with two spatial streams
  • Maximal ratio combining (MRC)
  • 20- and 40-MHz channels
  • PHY data rates up to 300 Mbps (40 MHz with 5 GHz)
  • Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
  • 802.11 dynamic frequency selection (DFS)
  • Cyclic shift diversity (CSD) support

802.11ac Wave 1 and 2 capabilities

  • 3x3 MIMO with two spatial streams, single-user or multiuser MIMO
  • MRC
  • 802.11ac beamforming (transmit beamforming)
  • 20-, 40-, and 80-MHz channels
  • PHY data rates up to 867 Mbps (80 MHz in 5 GHz)
  • Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
  • 802.11 DFS
  • CSD support

Regulatory Domain

S (S regulatory domain):

- 2.412 to 2.472 GHz; 13 channels

- 5.180 to 5.320 GHz; 8 channels

- 5.500 to 5.700 GHz; 11 channels

- 5.745 to 5.825 GHz; 5 channels

Integrated antenna

  • 2.4 GHz, gain 3 dBi, internal omni, horizontal beamwidth 360°
  • 5 GHz, gain 5 dBi, internal omni, horizontal beamwidth 360°

Interfaces

  • 1 x 10/100/1000BASE-T autosensing (RJ-45), Power over Ethernet (PoE)
  • Management console port (RJ-45)
  • USB 2.0 (enabled via future software)

Indicators

  • Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors

Dimensions (W x L x H)

  • Access point (without mounting bracket): 8.3 x 8.3 x 2 in. (210.8 x 210.8 x 50.8 mm)

Weight

  • 3.12 lb (1.41 kg)

Environmental

Cisco Aironet 1830i

  • Nonoperating (storage) temperature: -22° to 158°F (-30° to 70°C)
  • Nonoperating (storage) altitude test: 25˚C, 15,000 ft.
  • Operating temperature: 32° to 104°F (0° to 40°C)
  • Operating humidity: 10% to 90% (noncondensing)
  • Operating altitude test: 40˚C, 9843 ft.

System memory

  • 1 GB DRAM
  • 256 MB flash

Input power requirements

  • AP1830: 44 to 57 VDC
  • Power supply and power injector: 100 to 240 VAC; 50 to 60 Hz

Power draw

  • 15.4W

Note: When deployed using a PoE specification, the power drawn from the power sourcing equipment will be higher by some amount, depending on the length of the interconnecting cable.

Powering options

  • 802.3af/802.3at
  • Enhanced PoE
  • Cisco local power supply, AIR-PWR-C=
  • Cisco power injector, AIR-PWRINJ5= (Note:This injector supports 802.3af only), AIR-PWRINJ6=

Note: If 802.3af PoE is the source of power, the USB port is disabled.

Warranty

Limited lifetime hardware warranty

Vui lòng liên hệ để có giá tốt nhất

AIR-AP1832I-S-K9 : 802.11ac Wave 2; 3x3:2SS; Int Ant; S Reg Domain

Data sheet Cisco Aironet 1830 Series Access Points
