ASUSTOR LOCKERSTOR 10 (AS6510T): 10-bay Tower (up to 18-bay), Quad Core 2.1 GHz , 8GB RAM (up to 32GB)
Thiết bị lưu trữ NAS ASUSTOR LOCKERSTOR 10 (AS6510T)
| Product (SKU) | LOCKERSTOR 10 (AS6510T) |
|---|---|
| CPU | |
| CPU Model | Intel ATOM C3538 |
| CPU Architecture | x64 64-bit |
| CPU Frequency | Quad Core 2.1GHz |
| Memory | |
| Memory | 8GB SO-DIMM DDR4 |
| Memory Module Pre-installed | 8GB (1 x 8GB) |
| Total Memory Slots | 2 |
| Memory Expandable up to | 64GB (2 x 32GB) (Support mixed capacity) |
| Flash Memory | 4GB eMMC |
| Storage | |
| Drive Bays | 10 |
| M.2 Drive Slots | 2 |
| Compatible Drive Type |
|
| Maximum Drive Bays with Expansion Unit | 18 |
| External Ports | |
| Expansion | 2 x USB 3.2 Gen 1 |
| Network | 2 x 10 Gigabit Ethernet(10G/1G); 2 x 2.5 Gigabit Ethernet (2.5G/1G/100M) |
| Others | |
| System Fan | 2 x 120mm |
| LCD Panel | ✔ |
| Power Supply Unit / Adapter | 250W x1 |
| Input Power Voltage | 100V to 240V AC |
| Certification | FCC, CE, VCCI, BSMI, C-TICK |
| Warranty | 3 Years |
| Operation | |
| Power Consumption | 76.8 W (Operation) 41.1 W (Disk Hibernation) |
| Noise Level | 22dB (HDD idle) |
| Operation Temperature | 0°C~40°C (32°F~104°F) |
| Humidity | 5% to 95% RH |
| Size and Weight | |
| Size | 215.5(H) x 293(W) x 230(D) mm |
| Weight | 6.4 (kg) / 14.1 (lb) |
Data sheet ASUSTOR LOCKERSTOR 10 (AS6510T)
10-bay Tower (up to 18-bay), Quad Core 2.1 GHz , 8GB RAM (up to 32GB)
- CPU: Intel ATOM C3538 Quad-Core 2.1GHz, x64 64-bit
- Memory: 8GB (1 x 8GB) DDR4 SODIMM (Max.64GB)
- Total Memory Slots: 2
- Flash memory: 4GB eMMC
- Storage: 10 x 3.5" SATA HDD or 2.5" SATA HDD or 2.5" SATA SSD
- M.2 Drive Slots: 2 x M.2 PCIe (NVMe) / M.2 SATA (2280, 2260,2242)
- Max Internal Capacity: 180TB (18TB HDD X 10, Capacity may vary by RAID types)
- Maximum Capacity with Expansion Units: 324TB (18TB HDD X 18, Capacity may vary by RAID types)
- External Ports: USB 3.2 Gen 1 x 2
- LAN: 10 Gigabit Ethernet (10G/1G) x 2 + 2.5 Gigabit Ethernet (2.5G/1G/100M) x 2
- Maximum IP cam: 64 ( 4 free license included)
- Power Supply Unit / Adapter: Single 250W
- Expansion unit: AS6004U - 4 bay
- Toolless installation.
